Business：Supplier of LED lighting for indoor and outdoor, commercial and residential application, etc.. OEM / ODM acceptable, this site is only for wholesale business, if you are interested in drop-shipping retail business, please go to our B2C website www.lightsb
Website: www.lightsb2b.com; E-mail: sales@lightac.com
Please kindly note:
Below description is just for reference,
contact us if in need of more information.
Some items may upgrading without update here,it may exist the little difference, please kindly note it.
OEM customized is acceptable,We can suggest the items if you can provide the detail reqeuirements.
Front Cover: 304# or 316# Stainless Steel
Housing: Outdoor dark grey powder coated aluminum T=60-80um Adhesion of ISO class 1/ASTM class 4B
LED Source: 1x1W/1x2W/3xSMD5050 single color/3xSMD5050 RGB3in1 Cree/Bridgelux LED
Lens: Optical lens, efficiency ≥85%
Glass: Tempered step glass T=7mm
Glass pressure capacity: Full area=1700kgs
Gasket: Molding shaped silicone seal
Operating temperature: -20℃ to 40℃
Power cable: H05RN-F 2x0.75mm2 , L=0.5m (low voltage)
H05RN-F 3x0.75mm2 , L=0.5m (Single color/high voltage)
H05RN-F 4x0.75mm2 , L=0.5m (for RGB)
Mounting sleeve: ABS
Lifespan: 50000hours
3 years warranty
Optional PWM, 0/1-10V, DALI dimmable, DMX512
Size | Wattage | Leds Type | Color | Voltage | Material | IP | Beam Angle |
Dia55mm | 0.5W/1W/ 2W/ 3W/4W | High Power LEDS/ SMD | Single Color OR RGB/RGBW | DC12V /DC24V AC100-240V | SS304/SS316 | IP67 | 8/15/25/30/45/60 asymmetrical lens |
