Business：Supplier of LED lighting for indoor and outdoor, commercial and residential application, etc.. OEM / ODM acceptable, this site is only for wholesale business, if you are interested in drop-shipping retail business, please go to our B2C website www.lightsb
Website: www.lightsb2b.com; E-mail: sales@lightac.com
Please kindly note:
Below description is just for reference,
contact us if in need of more information.
Some items may upgrading without update here,it may exist the little difference, please kindly note it.
OEM customized is acceptable,We can suggest the items if you can provide the detail reqeuirements.
Features:
* Universal voltage:90-305VAC(50Hz/60Hz)
* High quality Epistar 3030.Excellent Optical* Internal safety isolated driver,Automatic temperature detection.PF>0.9,THD<8%.
* Die casting aluminum，Anodized surface,fadeless and corrosion resistant.
* Special heat dissipation structure/Flow linear design,excellent heat dissipation performance.
* Widely used in highway,Urban main road,station,Square,Gym,wharf,residential area and other occasions.
* IP Grade：IP65 IP66
| Power | 50W | 100W | 150W |
| Size | L560 * W196 * H99 mm | L610 * W245 * H99 mm | L661 * W245 * H99 mm |
| Lumen | 135LM/W | ||
| Beam angle | ＴＹＰＥ-Ⅱ/Ⅲ/Ⅳ/Ⅴ(optional) | ||
| Material | Die casting aluminum+PC lens | ||
| Interface Diameter | φ60mm/φ45mm（optional） | ||
EPE+Carton box, 595*225*160mm(1Pcs/CTN), Product N*W：3.4KG , G*W:3.9KG/CTN
Installation Instruction
★Before Installation,Ensure the voltage,Frequency is consistent with the voltage range specified on the product label.
★Must be installed and operated by qualified professionals,Read installation instruction carefully.
★Make sure the lamp installed firmly and wiring correct,To avoid short circuit to damage the lamp causing fire.
★Do not operate with electricity,
★Please check the circuit after installation then power on test, to avoid electric shock
* Make sure the ceiling or post can support the weight of lamp.
* The accessories must be installed firmly.
* Please check the circuit after installation then power on to do test,to avoid electric shock.
* Do not open the lamp privately to change the electrical structure,In case damage the lamp,The resulting damage is not covered
by the warranty.
* Do not soak the lamp into the water directly.
* Do not look at the lamp for long time to protect the eyes from damage.
