Please kindly note:
Below description is just for reference,
contact us if in need of more information.
Some items may upgrading without update here,it may exist the little difference, please kindly note it.
OEM customized is acceptable,We can suggest the items if you can provide the detail reqeuirements.
Features:
Housing for LED troffer:Light is made of high quality iron, rust and oil removed, under anti-rust treated and rust proof for 8-10 years under normal application, with white powder coating.
Diffuser for LED troffer:Polycarbonate, Acrylic LED Diffuser Specially for LED.
LED type for LED troffer:It use LED SMD 2835.
Electrical for LED troffer:Arcata ,X-power standard driver or 0-10v dimmable driver for LED line.
Mounting for LED troffer:Recessed mounting.
Main applications:1.Hotel / Hospital / Supermarket2.Conference / Meeting room / Factory / Office3.Bank / Institution Building4.School / College / University
Advantages:
High efficiency save energy:The light from the LED light is released through the diffuser directly, which isn't absorbed and reflected from other media. So the utilization of the light is relatively high, and the overall luminous efficiency of light is quite high. Energy saving, saving 65% than the traditional lights at the same brightness.
Luminous uniformity:It is designed to use the LED luminescence to make a reasonable LED distance, with the diffusion and the height of the light fixtures to achieve the ideal blend of light, so the reasonable distance between the LED SMD and the Polycarbonate or Acrylic LED Diffuser, so that it improves the brightness uniformity when it's lighting up.
Long life:It has a certain distance between the LED SMD and the diffuser. The heat dissipation provides enough space to ensure the long life of the light. The light life has more than 50000hrs.
Power | Leds | Luminous Flux (lm) | Efficiency (lm/w) | CRI | CCT |
30 | 2835 | 3750 | 125 | >80 | 3000K-6000K |
40 | 2835 | 5000 | 125 | >80 | 3000K-6000K |
50 | 2835 | 6250 | 125 | >80 | 3000K-6000K |
60 | 2835 | 7500 | 125 | >80 | 3000K-6000K |
Dimension (L*W*H) (inch) | Packing size (inch) | Qty/ctn |
23.80x23.80x2.95 | 24.40x24.40x6.70 | 2 |
23.80x23.80x2.95 | 24.40x24.40x6.70 | 2 |
47.25x23.80x2.95 | 47.65x24.40x6.70 | 2 |
47.25x23.80x2.95 | 47.65x24.40x6.70 | 2 |
High transmittance of polycarbonate diffuser for bright and uniform lighting distribution.
