Business：Supplier of LED lighting for indoor and outdoor, commercial and residential application, etc.. OEM / ODM acceptable, this site is only for wholesale business, if you are interested in drop-shipping retail business, please go to our B2C website www.lightsb
Website: www.lightsb2b.com; E-mail: sales@lightac.com
Please kindly note:
Below description is just for reference,
contact us if in need of more information.
Some items may upgrading without update here,it may exist the little difference, please kindly note it.
OEM customized is acceptable,We can suggest the items if you can provide the detail reqeuirements.
| Product model | LED Point Light-A | LED Point Lights-B | ||
| Input Voltage(V) | DC24V | DC48V | DC24V | DC48V |
| Working Lifetime(Hour) | ≥50000 | ≥50000 | ≥50000 | ≥50000 |
| Lamp Body Material | ABS+PC | ABS+PC | ABS+PC | ABS+PC |
| IP Rating | IP67 | IP67 | IP67 | IP67 |
| LED light source | 3535RGB*4+2835RGBW*2 | 3535RGB*8+2835RGBW*2 | 3535RGB*4+2835RGBW*2 | 3535RGB*8+2835RGBW*2 |
| Display color | RGBW | RGBW | RGBW | RGBW |
| Power | 3W | 3W | 3W | 3W |
| Color temperature | 3000K 4000K 5700K | 3000K 4000K 5700K | 3000K 4000K 5700K | 3000K 4000K 5700K |
| Lamp size | 56mm(L)*41.5mm(W)*14mm(H) | 56mm(L)*41.5mm(W)*14mm(H) | 56mm(L)*41.5mm(W)*14mm(H) | 56mm(L)*41.5mm(W)*14mm(H) |
| Warranty(Year) | 3-Year | 3-Year | 3-Year | 3-Year |
| control method | DMX | DMX | DMX | DMX |
| Gray scale | 16Bit | 16Bit | 16Bit | 16Bit |
| Beam angle | >120 | >120 | >120 | >120 |
| work temp | -20-60 | -20-60 | -20-60 | -20-60 |
| store temp | -40-75 | -40-75 | -40-75 | -40-75 |
1. High grayscale: 16bit grayscale level, smooth display, and rich colors;
2. Control: DMX512 control mode;
3. Multi voltage: covering working voltages of DC24V and DC48V;
4. Multiple mechanisms: support networking synchronization and asynchronous card insertion linkage mechanism;
5. Multiple spacing: standard spacing of 4 lights/m and 6 lights/m, supporting customized spacing;
6. Easy to install: compact in size, flat mounted with profiles, easy to install and maintain;
7. Standardization: Standard male and female plug-in foolproof wiring, standardized components, waterproof and foolproof, easy to operate and maintain;
8. Unification: Black light, black glue, black line, black glue head, gray light, white glue, gray line, gray glue head, with a unified and beautiful appearance;
9. High protection: The protection level is IP67, which not only adopts the double-sided three-dimensional non dead angle glue filling process, but also adopts the ultrasonic welding process in the manufacturing process, and adopts a secondary waterproof design;
10. High reliability: UV resistant, flame retardant V0 resistant, with a working life of 50000 hours.
Size Chart
